The CBHS-FL304 4 cc/rev Hydraulic Gear Pump is a high-performance, durable, and reliable pump designed for various applications in construction, agriculture, industrial vehicles, and material handling. It features a 10 cc/rev displacement, 20 MPa (2900 psi) rated pressure, and 2000 r/min rated speed, making it ideal for demanding environments.
| Řada CBHS-FL3 Hydraulické čerpadlo s ozubenými koly Parametry | |
|---|---|
| Zdvihový objem | 10 cm³/ot., 4 cm³/ot., 20 cm³/ot., 16 cm³/ot., 14 cm³/ot., 6 cm³/ot. |
| Jmenovitý tlak | 20 MP (2900 psi) |
| Maximální tlak | 25 MP (3625 psi) |
| Jmenovité otáčky | 2000 ot./min. |
| Maximální otáčky | 3000 ot./min. |
| Směr otáčení | L: Levý (proti směru hodinových ručiček), R: Pravý (po směru hodinových ručiček) |
| Materiál | Hliník |
| Konstrukce | Vnější zubové čerpadlo |
| Verze příruby | Příruba A - oválná |
| Typ hřídele | H: Obdélníková drážka, X: Evolutová drážka, P: Hladký klíč |
The CBHS-FL304 4 cc/rev Hydraulic Gear Pump is a robust and efficient internal gear pump, manufactured with high-quality aluminum material. It features an A-Oval flange design and a plain key shaft, making it compatible with various machinery. With a displacement of 10 cc/rev, a rated pressure of 20 MPa (2900 psi), and a rated speed of 2000 r/min, this pump delivers exceptional performance in demanding applications such as telehandlers, forklifts, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, tractors and front-end loaders, harvesters, and balers. The pump is also customizable to meet specific requirements. As a manufacturer, we provide manufacturing, OEM, private label, and customization services, along with global distribution network support.
