The PT-1220 Series Pneumatic 1 Spool Hydraulic Valve is a high-performance, factory-direct, and customizable valve designed for use in a wide range of construction, material handling, agricultural, and industrial vehicle applications. This valve offers a rated flow of 200 L/min (52 US gpm) and a maximum pressure of 315 bar (4600 psi), making it ideal for demanding applications.
| Řada DH30 Průtokový dělicí ventil Parametry | |
|---|---|
| Metoda řízení | Ruční |
| Šoupátko | 1 cívka |
| Jmenovitý průtok | 280 L/min (73,9 US gpm) |
| Maximální tlak | 210 bar (3045 psi) |
| Vstupní port | G1-1/4, G1-1/2 |
| Velikost portu | G1-1/4, G1-1/2 |
| Sekce | Sekce 1 |
| Typ konstrukce | Blokový ventil |
| Rozsah okolní teploty | -40 °C až +80 °C (-40 °F až +176 °F) |
| Rozsah provozní viskozity | 15 - 75 mm²/s (15 cSt až 75 cSt) |
The PT-1220 Series Pneumatic 1 Spool Hydraulic Valve is a high-performance, factory-direct, and customizable sectional valve designed for use in a variety of construction, material handling, agricultural, and industrial vehicle applications. Featuring a robust design and high-quality materials, this valve offers a rated flow of 200 L/min (52 US gpm) and a maximum pressure of 315 bar (4600 psi), making it ideal for demanding applications. The PT-1220 Series is known for its reliability and durability, with an operating viscosity range of 12 - 400 mm²/s (12 cSt to 400 cSt) and an ambient temperature range of -40°C to +80°C (-40°F to +176°F). This valve is compatible with a wide range of equipment, including telehandlers, forklifts, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, tractors and front-end loaders, harvesters, and balers.
